277V
max input
Voltage Compatibility
Supports 100-277V 50/60Hz input to match site power requirements.
Why Specify This Fixture
Product Highlights
SRK Linear Strip Retrofit
Product Configuration Matrix
24W - 3,120 Lumens · 4000K · 4ft
Click another row to change the selected SKU and quote target.
| SKU | Wattage - Lumens | Color Temperature | Fixture Length |
|---|---|---|---|
| SRK-4-3L-40K | 24W - 3,120 Lumens | 4000K | 4ft |
| SRK-4-3L-50K | 24W - 3,120 Lumens | 5000K | 4ft |
| SRK-4-5L-40K | 40W - 5,003 Lumens | 4000K | 4ft |
| SRK-4-5L-50K | 40W - 5,205 Lumens | 5000K | 4ft |
Performance Specifications
All listed models use 100-277V 50/60Hz input.
| Model # | Wattage | Lumens | CCT | CRI | PF | |
|---|---|---|---|---|---|---|
| SRK-4-3L | 24W | 3,120 lm | 4000K | ≥ 80 | ≥ 0.9 | |
| SRK-4-5L | 40W | 5,003 lm | 4000K | ≥ 80 | ≥ 0.9 |
Technical Specifications
| Electrical | |
|---|---|
| Input Voltage | 100-277V 50/60Hz |
| Power Factor | > 0.9 at full load |
| Thd | <20% full load |
| Operating temp | -20°C to 40°C Ambient (-4°F to 104°F) |
| Optical | |
| CCT | 4000K |
| Physical | |
| Weight | 4 39.7 lbs |
Compatible Accessories
Networked Lighting Controls
| Catalog Number | Description | Spec Sheet | Actions |
|---|---|---|---|
|
Jarvis Link Z10 Wireless Control Module (WCM) Bluetooth Z10 fixture controller; 0-10V dimming; IP65; White/Black/Bronze | Spec Sheet | View Product |
|
Jarvis Link Z10 PIR Motion Sensor + Photocell — Indoor/Outdoor Plug-in Z10 PIR + photocell; 8-40ft mount; UL8750 listed | Spec Sheet | View Product |
