Z10
receptacle
Z10 Accessory Ready
Pre-installed Z10 receptacle supports plug-in photocell, occupancy, and wireless control modules without rewiring.
Why Specify This Fixture
Product Highlights
LHB SERIES
10yr
warranty
Long-Term Warranty
Warranty coverage supports long-horizon maintenance planning for commercial retrofit projects.
120-480V
multi-voltage
Voltage Compatibility
Supports both 120-277V and 277-480V 50/60Hz input — one product family covers low-voltage and high-voltage site service.
Product Configuration Matrix
80W/100W/120W - 12,000/15,000/18,000 Lumens · 120-277V · 4000K / 5000K
Click another row to change the selected SKU and quote target.
| SKU | Wattage - Lumens | Voltage | Color Temperature |
|---|---|---|---|
| LHB-DCH-12ML18-40K/50K-Z10R | 80W/100W/120W - 12,000/15,000/18,000 Lumens | 120-277V | 4000K / 5000K |
| LHB-DCH-12ML18-40K/50K-HV-Z10R | 80W/100W/120W - 12,000/15,000/18,000 Lumens | 277-480V | 4000K / 5000K |
| LHB-DCH-18ML24-40K/50K-Z10R | 120W/140W/160W - 18,000/21,000/24,000 Lumens | 120-277V | 4000K / 5000K |
| LHB-DCH-18ML24-40K/50K-HV-Z10R | 120W/140W/160W - 18,000/21,000/24,000 Lumens | 277-480V | 4000K / 5000K |
| LHB-DCH-24ML33-40K/50K-Z10R | 160W/190W/220W - 24,000/28,500/33,000 Lumens | 120-277V | 4000K / 5000K |
| LHB-DCH-24ML33-40K/50K-HV-Z10R | 160W/190W/220W - 24,000/28,500/33,000 Lumens | 277-480V | 4000K / 5000K |
| LHB-DCH-30ML37-40K/50K-Z10R | 200W/225W/250W - 30,000/33,750/37,500 Lumens | 120-277V | 4000K / 5000K |
| LHB-DCH-30ML37-40K/50K-HV-Z10R | 200W/225W/250W - 30,000/33,750/37,500 Lumens | 277-480V | 4000K / 5000K |
| LHB-DCH-24ML45-40K/50K-Z10R | 160W/225W/300W - 24,000/33,750/45,000 Lumens | 120-277V | 4000K / 5000K |
| LHB-DCH-24ML45-40K/50K-HV-Z10R | 160W/225W/300W - 24,000/33,750/45,000 Lumens | 277-480V | 4000K / 5000K |
Performance & DLC Listings
| Model # | Wattage | Lumens | CCT | Input | DLC ID | CRI | PF | |
|---|---|---|---|---|---|---|---|---|
| LHB-DCH-24ML45-40K/50K-HV-Z10R | 304W | 46,074 lm | 4000K | 480V | S-8P7JZ5 | ≥ 86 | ≥ 0.961 | |
| LHB-DCH-24ML45-40K/50K-HV-Z10R-24L | 160W | 24,000 lm | 4000K | 480V | S-DYRVP8 | ≥ 86 | ≥ 0.888 | |
| LHB-DCH-24ML45-40K/50K-HV-Z10R-33L | 225W | 33,750 lm | 4000K | — | S-D887QZ | ≥ 86 | ≥ 0.932 | |
| LHB-DCH-24ML45-40K/50K-Z10R | 304W | 45,706 lm | 4000K | 120V | S-ZQPJ4L | ≥ 87 | ≥ 0.93 | |
| LHB-DCH-24ML45-40K/50K-Z10R-24L | 156.3W | 25,439 lm | 4000K | 120V | S-XFFXLG | ≥ 87 | ≥ 0.902 | |
| LHB-DCH-24ML45-40K/50K-Z10R-33L | 222.4W | 34,703 lm | 4000K | — | S-RKW52C | ≥ 87 | ≥ 0.89 |
Technical Specifications
| Electrical | |
|---|---|
| Input Voltage | 120-277V or 277-480V, 50/60Hz |
| Power Factor | > 0.9 at full load |
| Thd | <20% full load |
| Operating temp | -40°C to 50°C Ambient (-40°F to 122°F) |
| Optical | |
| CCT | 4000K |
| Physical | |
| Weight | 24ML45 7.2 lbs |
| Controls | |
| Motion Sensor | Compatible with a wide range of photo sensors and motion sensors. |
Compatible Accessories
Networked Lighting Controls
| Catalog Number | Description | Spec Sheet | Actions |
|---|---|---|---|
|
Jarvis Link Z10 Wireless Control Module (WCM) Bluetooth Z10 fixture controller; 0-10V dimming; IP65; White/Black/Bronze | Spec Sheet | View Product |
|
Jarvis Link Z10 PIR Motion Sensor + Photocell — Indoor/Outdoor Plug-in Z10 PIR + photocell; 8-40ft mount; UL8750 listed | Spec Sheet | View Product |
Other Accessories
| Catalog Number | Description | Spec Sheet | Actions |
|---|---|---|---|
|
Z10 PhotoMotion™ Custom Programming Remote Control PhotoMotion | Spec Sheet | View Product |
|
PIR Motion Sensor 120-277V Indoor Side Mount PhotoMotion™ Jarvis Lighting | Spec Sheet | View Product |
|
PhotoMotion™ Custom Programming Remote Control PhotoMotion | Spec Sheet | View Product |
