Z10
receptacle
Z10 Accessory Ready
Pre-installed Z10 receptacle supports plug-in photocell, occupancy, and wireless control modules without rewiring.
Why Specify This Fixture
Product Highlights
HBR LED High Bay Luminaire
10yr
warranty
Long-Term Warranty
Warranty coverage supports long-horizon maintenance planning for commercial retrofit projects.
PC
lens
Polycarbonate Lens
Lens and optical package are designed to maintain uniform distribution and visual comfort on site.
Product Configuration Matrix
80W / 110W / 150W - 13,000 / 15,400 / 20,000 lm · 3000K / 3500K / 4000K / 5000K
Click another row to change the selected SKU and quote target.
| SKU | Wattage-Lumens | Color emperature |
|---|---|---|
| HBR-G2-13ML20-30K/35K/40K/50K-90-WHT-Z10R | 80W / 110W / 150W - 13,000 / 15,400 / 20,000 lm | 3000K / 3500K / 4000K / 5000K |
| HBR-G2-23ML30-30K/35K/40K/50K-90-WHT-Z10R | 165W / 190W / 220W - 23,100 / 26,600 30,600 lm | 3000K / 3500K / 4000K / 5000K |
Performance Specifications
All listed models use 120-277V 50/60Hz input.
| Model # | Wattage | Lumens | CCT | CRI | PF | |
|---|---|---|---|---|---|---|
| HBR-G2-13ML20-30K/35K/40K/50K-90 | 80W / 110W / 150W / 165W / 190W | 20,000 lm | 3000K / 3500K / 4000K / 5000K | ≥ 80 | ≥ 0.9 | |
| HBR-G2-23ML30-30K/35K/40K/50K-90 | 220W | 30,600 lm | 4000K / 5000K | ≥ 80 | ≥ 0.9 |
Technical Specifications
| Electrical | |
|---|---|
| Input Voltage | 120-277V 50/60Hz |
| Power Factor | > 0.9 at full load |
| Thd | <20% full load |
| Operating temp | -20°C to 45°C Ambient (-4°F to 113°F) |
| Physical | |
| Weight | 13ML20 3.3lbs; 23ML30 4.4lbs |
Compatible Accessories
Networked Lighting Controls
| Catalog Number | Description | Spec Sheet | Actions |
|---|---|---|---|
|
Jarvis Link Z10 Wireless Control Module (WCM) Bluetooth Z10 fixture controller; 0-10V dimming; IP65; White/Black/Bronze | Spec Sheet | View Product |
|
Jarvis Link Z10 PIR Motion Sensor + Photocell — Indoor/Outdoor Plug-in Z10 PIR + photocell; 8-40ft mount; UL8750 listed | Spec Sheet | View Product |
Other Accessories
| Catalog Number | Description | Spec Sheet | Actions |
|---|---|---|---|
|
Z10 PhotoMotion™ Custom Programming Remote Control PhotoMotion | Spec Sheet | View Product |
|
PIR Motion Sensor 120-277V Indoor Side Mount PhotoMotion™ Jarvis Lighting | Spec Sheet | View Product |
|
PhotoMotion™ Custom Programming Remote Control PhotoMotion | Spec Sheet | View Product |
