120-277V
universal
Voltage Compatibility
Accepts universal 120-277V 50/60Hz input across standard commercial service.
Why Specify This Fixture
Product Highlights
HBL-SC LED Linear High Bay Luminaire
Product Configuration Matrix
165W - 22,630 Lumens · UV - 120-277V · 5000K
Click another row to change the selected SKU and quote target.
| SKU | Wattage-Lumens | Voltage | Color Temperature |
|---|---|---|---|
| HBL-SC-1x2-22L-50K-Z10R | 165W - 22,630 Lumens | UV - 120-277V | 5000K |
Performance Specifications
All listed models use 277V 50/60Hz input.
| Model # | Wattage | Lumens | CCT | CRI | PF | |
|---|---|---|---|---|---|---|
| HBL-12-12L-40K-1X2-WHITE-LINEAR-HIGH-BAY-MLH0490W27V40KCD | 90W | 12,600 lm | 4000K | ≥ 80 | ≥ 0.9 | |
| HBL-12-12L-50K-1X2-WHITE-LINEAR-HIGH-BAY-MLH0490W27V50KCD | 90W | 12,600 lm | 5000K | ≥ 80 | ≥ 0.9 | |
| HBL-12-18L-40K-1X2-WHITE-LINEAR-HIGH-BAY-MLH04130W27V40KCD | 130W | 18,500 lm | 4000K | ≥ 80 | ≥ 0.9 | |
| HBL-12-18L-50K-1X2-WHITE-LINEAR-HIGH-BAY-MLH04130W27V50KCD | 130W | 18,500 lm | 5000K | ≥ 80 | ≥ 0.9 | |
| HBL-22-25L-40K-2X2-WHITE-LINEAR-HIGH-BAY-MLH04180W27V40KCD | 180W | 25,200 lm | 4000K | ≥ 80 | ≥ 0.9 | |
| HBL-22-25L-50K-2X2-WHITE-LINEAR-HIGH-BAY-MLH04180W27V50KCD | 180W | 25,200 lm | 5000K | ≥ 80 | ≥ 0.9 | |
| HBL-22-29L-40K-2X2-WHITE-LINEAR-HIGH-BAY-MLH04210W27V40KCD | 210W | 29,000 lm | 4000K | ≥ 80 | ≥ 0.9 | |
| HBL-22-29L-50K-2X2-WHITE-LINEAR-HIGH-BAY-MLH04210W27V50KCD | 210W | 29,000 lm | 5000K | ≥ 80 | ≥ 0.9 | |
| HBL-24-35L-40K-2X4-WHITE-LINEAR-HIGH-BAY-MLH03270W27V40KCD | 270W | 35,500 lm | 4000K | ≥ 80 | ≥ 0.9 | |
| HBL-24-35L-50K-2X4-WHITE-LINEAR-HIGH-BAY-MLH03270W27V50KCD | 270W | 36,000 lm | 5000K | ≥ 80 | ≥ 0.9 | |
| HBL-24-40L-40K-2X4-WHITE-LINEAR-HIGH-BAY-MLH03300W27V40KCD | 300W | 39,500 lm | 4000K | ≥ 80 | ≥ 0.9 | |
| HBL-24-40L-50K-2X4-WHITE-LINEAR-HIGH-BAY-MLH03300W27V50KCD | 300W | 40,000 lm | 5000K | ≥ 80 | ≥ 0.9 | |
| HBL-24-50L-40K-2X4-WHITE-LINEAR-HIGH-BAY-MLH04370W27V40KCD | 370W | 50,500 lm | 4000K | ≥ 80 | ≥ 0.9 | |
| HBL-24-50L-50K-2X4-WHITE-LINEAR-HIGH-BAY-MLH04370W27V50KCD | 370W | 50,500 lm | 5000K | ≥ 80 | ≥ 0.9 |
Technical Specifications
| Electrical | |
|---|---|
| Input Voltage | 120-277V 50/60Hz |
| Power Factor | > 0.9 at full load |
| Thd | <20% full load |
| Operating temp | -40°C to 55°C Ambient (-40°F to 131°F) |
| Optical | |
| CCT | 4000K / 5000K |
| Controls | |
| Dimming | 0-10V dim-to-off with 12V auxiliary power for accessories. |
Compatible Accessories
Networked Lighting Controls
| Catalog Number | Description | Spec Sheet | Actions |
|---|---|---|---|
|
Jarvis Link Z10 PIR Motion Sensor + Photocell — Indoor/Outdoor Plug-in Z10 PIR + photocell; 8-40ft mount; UL8750 listed | Spec Sheet | View Product |
Other Accessories
| Catalog Number | Description | Spec Sheet | Actions |
|---|---|---|---|
|
Z10 PhotoMotion™ Custom Programming Remote Control PhotoMotion | Spec Sheet | View Product |
|
PIR Motion Sensor 120-277V Indoor Side Mount PhotoMotion™ Jarvis Lighting | Spec Sheet | View Product |
|
PhotoMotion™ Custom Programming Remote Control PhotoMotion | Spec Sheet | View Product |
