Z10
receptacle
Plug-In Z10 Install
Quick-connect install into any Jarvis Lighting fixture with a factory Z10 receptacle — no rewiring, no driver changes at commissioning.
Why Specify This Fixture
Product Highlights
Sensor
360°
coverage
Detection Zone / Angle
Maximum coverage 40ft diameter from 40ft mounting height with 360° PIR detection and integrated photocell for daylight-harvesting control.
40ft
mount
High Mounting Height
Rated for mounting heights up to 40ft (12m) — covers high-bay warehouses, outdoor area lighting, and parking garages from a single sensor.
IP65
rated
Indoor / Outdoor Rated
Sealed IP65 enclosure with -20°C to 60°C operating range — one SKU family covers interior and exterior applications in Black or White.
Product Configuration Matrix
12-24VDC · Black
Click another row to change the selected SKU and quote target.
| SKU | Rated Voltage | Color |
|---|---|---|
| JL-Z10-SPM-INT/EXT-BLK | 12-24VDC | Black |
| JL-Z10-SPM-INT/EXT-WHT | 12-24VDC | White |
Technical Specifications
| Electrical | |
|---|---|
| Input Voltage | 12-24VDC |
| Current consumption | >50mA |
| Output | 0-10V, max 25mA sinking current (Active High 3.6W) |
| Operating temp | -20°C to 60°C (-4°F to 140°F) |
| Controls | |
| Sensor type | PIR sensor with integrated photocell |
| Mesh | Bluetooth SIG mesh |
| Detection angle | 360° |
| Mounting height max | 40ft (12m) |
| Max bluetooth range | 200ft (61m) |
| Compliance | |
| Ip rating | IP65 |
| Dlc nlc id | N-Z4E37G |
Compatible Accessories
Networked Lighting Controls
| Catalog Number | Description | Spec Sheet | Actions |
|---|---|---|---|
|
Jarvis Link Z10 Wireless Control Module (WCM) Bluetooth Z10 fixture controller; 0-10V dimming; IP65; White/Black/Bronze | Spec Sheet | View Product |
|
JL-Z10-RTC-BLK-LR-V1-BBZ
|
Jarvis Link Z10 Long Range Time Management Controller (RTC) Z10 time-management controller; 30-day battery; 1,200ft mesh; 0-10V dim | Spec Sheet | View Product |
|
Jarvis Link IoT Gateway (JL150) Jarvis Link gateway; ~200 mesh devices; PoE/Wi-Fi; scheduling + energy | Spec Sheet | View Product |
|
Jarvis Link Z10 Long Range Wireless Control Module — Clear Housing Long-range Z10 fixture controller; 1,200ft mesh; 0-10V dimming; IP65 | Spec Sheet | View Product |
